Virnig V20 Root Rake Grapple for Mini Skid Steer
The Virnig V20 Root Rake Grapple is a compact, rugged attachment designed for mini skid steers that clears brush fast by digging, raking, piling, and loading debris. Built for landscapers, property teams, and small‑scale contractors who need real productivity in tight spaces, it delivers dependable performance without overburdening your machine.
- Available widths: 36", 42", 48" to fit a range of mini skid steers and job site requirements
- One-piece tine construction: Every tine is forged from a single piece of steel for maximum rigidity and reduced flex during heavy brush work
- Rigidity and durability: Built light yet tough with a compact profile that handles demanding clearing tasks
- High‑quality components: NitroSteel cylinder rods and TEFLON® coated bushings on all pivots for long wear and smooth operation
- Grapple jaw opening: 32.2 inches to grab sizeable brush, roots, and debris securely
- Mounting compatibility: Toro, Mini‑Universal, Bobcat, and ASV skid steer mounts (universal quick tach mount not available)
- Key dimensions by model: CRG36—overall width 35.8", CRG42—43.8", CRG48—51.8" with height 24.7"/23.6" and depth 21.5"
- Number of tines (with sides): 6 (CRG36), 7 (CRG42), 8 (CRG48)
- Space between tines / grapple jaws: 6.8"/7.2" (CRG36), 7.0"/7.3" (CRG42), 7.1"/7.4" (CRG48)
- Tine thickness: 0.375 inches
- Cylinder bore / stroke: 2.0"/6.0"
- Cylinder pins / hinge pins: 1.0" diameter
- Approximate weight: 270 lb (CRG36), 300 lb (CRG42), 335 lb (CRG48)
- Loader capacity alignment: Recommended loader capacity greater than 500 pounds
The V20 Root Rake Grapple is designed to help you tackle brush clearing with confidence. The combination of a rigid one-piece tine design and low‑friction, long‑wear components means you can repeatedly rake and pile without frequent maintenance. NitroSteel cylinder rods resist wear in tough, abrasive environments, while TEFLON® coated bushings reduce friction at pivots for smoother operation over time. The varied widths and corresponding tine counts let you tailor the attachment to narrow trails, dense brush, or open clearing jobs, maximizing efficiency on every pass.
| MODEL | CRG36 | CRG42 | CRG48 |
| Overall Width (Inches) | 35.8 | 43.8 | 51.8 |
| Height: Overall / Bucket (Inches) | 24.7 / 23.6 | ||
| Overall Depth (Inches) | 21.5 | ||
| Number of Tines (With Sides) | 6 | 7 | 8 |
| Space Between Tines / Grapple Jaws (Inches) | 6.8 / 7.2 | 7.0 / 7.3 | 7.1 / 7.4 |
| Tine Thickness (Inches) | 0.375¹ | ||
| Cylinder Bore / Stroke (Inches) | 2.0 / 6.0 | ||
| Cylinder Pins / Hinge Pins Diameter (Inches) | 1.0 / 1.0 | ||
| Grapple Jaw Opening (Inches) | 32.2 | ||
| Approximate Weight (Pounds) | 270 | 300 | 3352 |
| Recommended Loader Capacity | Greater than 500 pounds | Greater than 500 pounds | Greater than 500 pounds |
